Product Details

It is a switched rack PDU with a maximum current capacity of 30A and an input voltage of 208V. It includes 16 IEC C13 outlets and a NEMA L6-30P input connection. The PDU has a 2U form factor and a cord length of 12 feet. It supports remote monitoring and user-defined alarms, with outlet-level on/off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.

Product Specifications

Manufacturer	APC by Schneider Electric
Manufacturer Part Number	AP7911B
GTIN / Barcode	0731304331605
Brand Name	APC by Schneider Electric
Product Name	APC Rack PDU, Switched, 2U, 30A, 208V, (16)C13

Design
Mfr. Part Number	AP7911B
GTIN / Barcode	0731304331605
PDU types	Switched
Rack capacity	2U
Product colour	Black
Ports & interfaces
AC outlets quantity	16 AC outlet(s)
AC outlet types	C13 coupler
Input connection type	NEMA L6-30P
Features
LED indicators	Yes
Cable length	3.65 m
Management features
Monitoring	Current
Outlet control	Recycle, Turn off
Power
Nominal input voltage	200; 208; 230 V
AC input frequency	50 - 60 Hz
Maximum current	30 A
Output voltage	208 V
Maximum input current per phase	30 A
Maximum total current draw per phase	30 A
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Compliance certificates	RoHS, REACH, WEEE
Certification	cUL listed; CSA; Industry Canada; PSE; UL listed
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15000 m
Weight & dimensions
Width	445 mm
Depth	254 mm
Height	89 mm
Weight	6.32 kg
Packaging data
Package weight	8.36 kg
Package width	514 mm
Package depth	514 mm
Package height	146 mm
Technical details
Sustainable packaging	No
Packaging recycled materials	Recycled cardboard
SCIP number	1cdb2fed-a06f-4574-913d-8df8e70936b2
Removable battery	Yes
Preferred mounting position	no preference
Take-back system	No
Packaging without single use plastic	No
Logistics data
Country of origin	India
Customs product code (TARIC)	8537109899
Total carbon footprint (kg of CO2e)	2004.7916791594
