Product Details

It is a switched rack PDU with maximum current capacity of 20A and an input voltage of 208V. It features 21 C13 and C15 outlets and 3 C19 and C21 outlets, connected via an IEC 60320 L6-20P plug. This PDU is designed for ZeroU mounting.

Product Specifications

Manufacturer	APC by Schneider Electric
Manufacturer Part Number	APDU9959NA3
GTIN / Barcode	0731304356301
Brand Name	APC by Schneider Electric
Product Name	APC Rack PDU 9000 Switched, ZeroU, 20A, 208V, (21) C13/C15 & (3) C19/C21, L620 Cord

Design
Mfr. Part Number	APDU9959NA3
GTIN / Barcode	0731304356301
PDU types	Switched
Rack capacity	0U
Mounting	Vertical
Product colour	Black
Ports & interfaces
AC outlets quantity	24 AC outlet(s)
Power plug	NEMA L6-20P
AC outlet types	C13 coupler, C15 coupler, C19 coupler, C21 coupler
Input connection type	IEC 60320 L6-20P
Power
Nominal input voltage	200; 208 V
AC input frequency	50 - 60 Hz
Maximum current	20 A
Nominal output voltage	200 - 208 V
Output voltage	208 V; 200 V
Load capacity	3300 VA
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Compliance certificates	RoHS, REACH, WEEE
Certification	cUL listed; FCC part 15 class A; PSE
Operational conditions
Operating temperature (T-T)	-5 - 60 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 15240 m
Weight & dimensions
Width	55 mm
Depth	46 mm
Height	1797 mm
Weight	5.61 kg
Packaging data
Package weight	7.86 kg
Package width	165 mm
Package depth	114 mm
Package height	2002 mm
Technical details
Sustainable packaging	No
Packaging recycled materials	Recycled cardboard
SCIP number	31346aed-552c-4a16-81d9-e683a383b6da
Removable battery	Yes
Preferred mounting position	no preference
Take-back system	No
Packaging without single use plastic	No
Logistics data
Country of origin	India
Customs product code (TARIC)	8537109899
Total carbon footprint (kg of CO2e)	1550.2280268984
Warranty period	3 year(s)
