Name: TP-Link IES206GPP network switch Managed Gigabit Ethernet (10/100/1000) Power over (PoE) Black
Brand: TP-Link
SKU: IES206GPP
Price: 199.99 USD
Availability: InStock

856-283-0457 sales@centraldistributor.com 81 Erial Rd Apt B, Clementon, NJ, 08021

Home /Networking & Communications /Network Switches /TP-Link IES206GPP network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Product Details

Industrial-Grade Protection Built for Harsh Environments

Enhanced Networking Stability and Security

Easy Operation and Maintenance with Omada’s Free Cloud Management

Product Specifications

Manufacturer	TP-Link
Manufacturer Part Number	IES206GPP
GTIN / Barcode	1210002602051
Brand Name	TP-Link
Product Name	TP-Link IES206GPP network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Management features
Mfr. Part Number	IES206GPP
GTIN / Barcode	1210002602051
Switch type	Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	1
SFP module slots quantity	1
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
10G support	No
Port mirroring	Yes
Flow control support	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Auto MDI/MDI-X	Yes
Spanning tree protocol	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Auto-negotiation	Yes
Data transmission
Switching capacity	12 Gbit/s
Forwarding rate	8.93 Mpps
MAC address table	8000 entries
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	15000
Security
DHCP features	DHCP client
IGMP snooping	Yes
Multicast features
Multicast support	Yes
Design
Rack mounting	Yes
Product colour	Black
Wall mountable	Yes
DIN rail mounting	Yes
Performance
Fanless	Yes
Power
Power source	DC/PoE
Redundant power supply (RPS) support	Yes
DC input voltage	12 - 57 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	PoE+, PoE++ (4PPoE)
Power over Ethernet plus (PoE+) ports quantity	3
Power over Ethernet 4PPoE (PoE++) ports quantity	1
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	120 W
Operational conditions
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	155 mm
Depth	120 mm
Height	60 mm
Packaging content
Quick start guide	Yes
Certificates
Certification	FCC, CE, RoHS
Brand	TP-Link
Availability	In Stock
Price Currency	USD
Category	Network Switches
