Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling
The RS232EXTC1 Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-RS232EXTC1
GTIN / Barcode
0065030841863
Brand Name
StarTech.com
Product Name
StarTech.com RS232 Serial over Cat5 Extender, 1 km (3300 ft) Range, Plug & Play, No Software, DB9 Serial Extension - TAA
Mfr. Part Number
STA-RS232EXTC1
GTIN / Barcode
0065030841863
Performance
Type
Network receiver
Maximum transfer distance
1000 m
Cable types supported
Cat5
Network
Cabling technology
10/100Base-T(X)
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
Design
Product colour
Silver
Power
Input current
0.055 A
Output voltage
9 V
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
0 - 85 °C
Operating relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
34 mm
Depth
92 mm
Height
22 mm
Weight
65 g
Packaging data
Package width
144 mm
Package depth
316 mm
Package height
58 mm
Certificates
Compliance certificates
RoHS
Logistics data
Master (outer) case width
330 mm
Master (outer) case length
334 mm
Master (outer) case height
318 mm
Products per master (outer) case
10 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Cabling
