Home/Networking & Communications/StarTech.com Multi-Mode (MM) ST Fiber Media Converter for 10/100Mbps Networks, Standalone Ethernet to ST MM Fiber Media Converter, 1310nm, 2km - TAA
StarTech.com
StarTech.com Multi-Mode (MM) ST Fiber Media Converter for 10/100Mbps Networks, Standalone Ethernet
Availability: In StockMfr. Part#: MCM110ST2
$109.12Save 5% · $5.20
$103.92USD
Prices shown in USD. Taxes, duties and freight are quoted separately.
Call 856-283-0457 for volume pricing.
Business & Quantity Discounts Available
Flexible Terms for Qualified Organizations
Supporting Commercial, Government & Education Buyers
Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode ST fiber
The MCM110ST2 10/100 Multi Mode ST Fiber Ethernet Media Converter (2 km) creates a cost-effective Ethernet to fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over a multimode fiber backbone. The ST media converter supports a maximum multimode fiber optic cable distance of 2km (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using ST-terminated multimode fiber, while delivering solid network performance and scalability. Easy to setup and install, this compact, value-conscious fast Ethernet media converter features auto-switching MDI and MDI-X support on the RJ45 UTP connections as well as manual controls for UTP mode, speed, Full and Half Duplex, as well as LFP (Link Fault pass-through) on/off.
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
MCM110ST2
GTIN / Barcode
0065030835633
Brand Name
StarTech.com
Product Name
StarTech.com Multi-Mode (MM) ST Fiber Media Converter for 10/100Mbps Networks, Standalone Ethernet to ST MM Fiber Media Converter, 1310nm, 2km - TAA
Mfr. Part Number
MCM110ST2
GTIN / Barcode
0065030835633
Network
Maximum data transfer rate
100 Mbit/s
Converter input interface
10Base-T, 100BASE-FX, 100Base-TX
Networking standards
IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates
10,100 Mbit/s
Data transfer rate
100 Mbit/s
Duplex system
Full, Half
Performance
Maximum transfer distance
2000 m
Wavelength
1310 nm
Wavelength-division multiplexing (WDM)
No
Sensitivity
-31 dBmW
Link budget
11 dB
Mean time between failures (MTBF)
65000 h
Features
Internal
No
LED indicators
Yes
Housing material
Plastic
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Fiber optic connector
ST
Power
Input voltage
100 - 240 V
Output voltage
12 V
Output current
0.2 A
Power consumption (typical)
2.4 W
Power over Ethernet (PoE)
No
Power plug type
Type M
Weight & dimensions
Width
75 mm
Depth
95 mm
Height
20 mm
Weight
82 g
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Packaging content
AC adapter included
Yes
Manual
Yes
Packaging data
Package width
145 mm
Package depth
175 mm
Package height
61 mm
Package weight
273 g
Certificates
Compliance certificates
RoHS
Certification
CE, FCC, TAA, REACH
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Networking & Communications
