Amplify the strength of your HDMI signal to extend your video source up to 115 ft. over standard HDMI cable
This HDMI signal booster lets you increase the signal strength of your HDMI video source so you can connect an HDMI display up to 115 ft. (35 m) away, using standard HDMI cables. You can place the booster inline between two HDMI cables, up to 82 ft. in length at the video input, and up to 33 ft. in length at the video output.
Discreet installation
With its small form factor, the HDMI booster is easy to hide, for a discreet installation. You don’t need an external power adapter to operate the signal booster, and it includes mounting hardware, so installing it is hassle-free. By extending your video signal using standard HDMI cables, the HDMI booster is a cost-effective alternative to more expensive HDMI extension systems that require the installation of CAT5 or CAT6 cabling infrastructure.
Compatible with varying distances
The HDMI booster features an equalization switch with ten different levels. The equalization switch lets you adjust the amplification of your HDMI signal based on the distance of your cables, so that you can ensure your HDMI signal will be perfect even at distances up to 115 ft. (35 m). The booster is perfect for boardrooms, offices or classrooms that may require varying distances depending on the room size.
Maintains high-definition video signals
When extending HDMI over long distances using standard video cabling, higher resolutions can become unavailable. Using the HDMI signal booster ensures that you’ll still be able to depend on high-definition resolutions up to 1080p at 60Hz.
The HDBOOST is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
HDBOOST
GTIN / Barcode
0065030863209
Brand Name
StarTech.com
Product Name
StarTech.com HDMI Signal Booster - 115 ft - 1080p
Mfr. Part Number
HDBOOST
GTIN / Barcode
0065030863209
Features
Type
AV repeater
Maximum resolution
1920 x 1080 pixels
Maximum transfer distance
35 m
Audio system
Multichannel
Audio output channels
7.1 channels
LED indicators
Power
Supported video modes
720p, 1080p
Supported graphics resolutions
1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+)
Rack mounting
Yes
Product colour
Black
Certification
CE, FCC
Ports & interfaces
HDMI in
1
Number of HDMI outputs
1
DC-in jack
Yes
Power
AC input voltage
100-240 V
Operating voltage
5 V
Output current
1 A
Power plug type
Type N
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-10 - 80 °C
Operating relative humidity (H-H)
5 - 90%
Weight & dimensions
Dimensions (WxDxH)
42.2 x 54.2 x 26.2 mm
Weight
72 g
Packaging data
Package dimensions (WxDxH)
143 x 168 x 63 mm
Package width
143 mm
Package depth
174 mm
Package height
33 mm
Package weight
163 g
Packaging content
Mounting brackets included
Yes
Technical details
Audio support
Yes
Compliance certificates
RoHS
Logistics data
Harmonized System (HS) code
85176200
Master (outer) case width
570 mm
Master (outer) case length
538 mm
Master (outer) case height
314 mm
Products per master (outer) case
100 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Cables & Connectivity
