4K HDMI® Balun | Visually Lossless Compression | IR Support
This HDMI® over CAT6 extender lets you transmit your HDMI signal over a CAT6 cable up to 330 ft. (100 m) away. The extender supports Ultra HD 4K with support for 3D and the accompanying digital audio.
Long-Distance Transmission
Extend your HDMI signal to up to 330 ft. (100 m) with this HDMI over Ethernet extender. Use your existing CAT6 cable infrastructure with a direct connection to the converter for an easy run through walls and ceilings, saving you on installation costs.
The extender also works to extend an infrared (IR) signal, enabling you to control your video source from the remote location.
Astonishing 4K Picture Quality
This HDMI Ethernet extender supports a 4K 60Hz (3840 x 2160) UHD resolution, providing four times the picture quality of high-definition (1080p), ensuring a crystal-clear picture that's ideal for displaying your 4K video content in office buildings, airports, retail settings and more.
Plus, because the extender supports 1080p and lower resolutions at up to 460 feet away, you can comfortably use this extender to make any video source look great.
Compatible with HDCP 2.2 Devices
Connect your HDMI devices and displays with confidence, knowing this extender is HDCP 2.2 compliant. This lets you harness the capabilities of HDMI-enabled devices such as Blu-ray players or online streaming devices in higher resolutions. It is also backward compatible with previous generations of HDMI and HDCP.
ST121HD20L is backed by 2-year StarTech.com warranty with free lifetime technical support.
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
ST121HD20L
GTIN / Barcode
0065030882637
Brand Name
StarTech.com
Product Name
StarTech.com HDMI over CAT6 Extender - 4K 60Hz - 330 ft. (100 m) - TAA
Mfr. Part Number
ST121HD20L
GTIN / Barcode
0065030882637
Features
Type
AV transmitter & receiver
Maximum resolution
3840 x 2160 pixels
Cable types supported
Cat6
Maximum transfer distance
140 m
Chipset
Norelsys NS 5730, NS5731
Maximum refresh rate
60 Hz
Audio output channels
7.1 channels
LED indicators
Link, Power
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA)
HDCP
Yes
Material
Metal
HDCP version
1.4/2.2
Product colour
Black
Ports & interfaces
Connectivity technology
Wired
RJ-45 input ports
1
RJ-45 output ports
1
HDMI in
1
Number of HDMI outputs
1
Serial ports quantity
2
Remote (IR) input
2
Remote (IR) output
2
DC-in jack
Yes
Power
AC input voltage
110 - 240 V
Operating voltage
5 V
Output current
2 A
External power adapter
Yes
Power plug type
Type M
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-15 - 55 °C
Operating relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
111 mm
Depth
76 mm
Height
26 mm
Weight
271 g
Packaging data
Package width
250 mm
Package depth
201 mm
Package height
99 mm
Package weight
1.42 kg
Packaging content
AC adapter included
Yes
Cables included
LAN (RJ-45)
Included power plug types
ANZ, EU, JP, NA, UK
Quick start guide
Yes
Mounting brackets included
Yes
Logistics data
Master (outer) case width
420 mm
Master (outer) case length
500 mm
Master (outer) case height
280 mm
Products per master (outer) case
10 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Cables & Connectivity
