Home/Networking & Communications/Network Switches/StarTech.com HDMI Extender over CAT6 with 3 Port Video Switch, 4K 30Hz/115ft, HDBaseT HDMI Extender Kit, IR Control, 4K Video over Ethernet w/ Automatic HDMI Switcher, HDMI Switch Box - TAA
StarTech.com
StarTech.com HDMI Extender over CAT6 with 3 Port Video Switch, 4K 30Hz/115ft, HDBaseT Kit, IR
Availability: In StockMfr. Part#: STA-VS321HDBTK
$266.75Save 5% · $12.70
$254.05USD
Prices shown in USD. Taxes, duties and freight are quoted separately.
Call 856-283-0457 for volume pricing.
Business & Quantity Discounts Available
Flexible Terms for Qualified Organizations
Supporting Commercial, Government & Education Buyers
HDBaseT™ Extender| 4K 30Hz | Automatic Switch | Mac & Windows
This HDMI over CAT6 extender with 3-port HDMI switch features HDBaseT™ and is TAA Compliant.
Astonishing 4K over CAT6
This HDMI Extender with a built-in Switch is capable of extending 7.1 audio and 4K at 30Hz video up to 115ft (35m), or 1080p up to 230ft (70m). The transmitter and receiver kit is connected using a single CAT5e/6 cable to avoid the hassle of running multiple cables.
Simplified Professional Installation
The HDMI Switch Box and Extender supports Power-over-Cable, meaning both the transmitter and receiver can be powered by the same single power source. Power-over-Cable is great for extending video to areas where power outlets may be limited, such as industrial sites. Use the metal housing, grounding bolts and included mounting brackets to create professional installation options, ideal for digital signage, boardrooms, and tradeshow applications.
Effortless Control with Automatic Switching
The 4K 30Hz HDMI extender box features several methods of input adjustment. Auto-detect switching selects newly connected devices, whereas priority selection allows you to choose the default active port. The IR Remote Control (batteries not included) and serial switching, using the included RJ-11 to DB9 adapter, offer additional input selection methods.
VS321HDBTK is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-VS321HDBTK
GTIN / Barcode
0065030880091
Brand Name
StarTech.com
Product Name
StarTech.com HDMI Extender over CAT6 with 3 Port Video Switch, 4K 30Hz/115ft, HDBaseT HDMI Extender Kit, IR Control, 4K Video over Ethernet w/ Automatic HDMI Switcher, HDMI Switch Box - TAA
Mfr. Part Number
STA-VS321HDBTK
GTIN / Barcode
0065030880091
Features
Type
AV transmitter & receiver
Maximum resolution
4096 x 2160 pixels
Cable types supported
Cat5e, Cat6
Maximum transfer distance
70 m
Chipset
VS010TX, VS010RX
Maximum refresh rate
60 Hz
Extended display identification data (EDID)
Yes
Audio output channels
7.1 channels
LED indicators
Yes
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160, 4096 x 2160
HDCP
Yes
Material
Metal
Rubber feet
Yes
HDCP version
1.4
Product colour
Black
HDBaseT certified
Yes
Ports & interfaces
Connectivity technology
Wired
RJ-45 input ports
1
RJ-45 output ports
1
HDMI in
3
Number of HDMI outputs
1
RJ-11 ports quantity
1
DC-in jack
Yes
Power
AC input voltage
100 - 240 V
Input current
0.6 A
Output current
1.5 A
Power consumption (typical)
18 W
Power plug type
Type M
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 90%
Packaging data
Package width
216 mm
Package depth
296 mm
Package height
69 mm
Package weight
173 g
Packaging content
Cables included
Phone (RJ-11)
Included power plug types
ANZ, EU, JP, NA, UK
Quick start guide
Yes
Remote control included
Yes
Mounting brackets included
Yes
Technical details
Compliance certificates
CE, RoHS
Logistics data
Master (outer) case width
410 mm
Master (outer) case length
323 mm
Master (outer) case height
275 mm
Products per master (outer) case
6 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Switches
