Convert and extend a Gigabit Ethernet connection up to 24.8 miles/40 km over Single Mode SC fiber The ET91000SM402 1000 Mbps Gigabit Single Mode Fiber Media Converter SC (40 km) lets you extend a Gigabit Ethernet network over single mode fiber by up to 40km (25 miles). A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required. For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). Backed by a StarTech.com 2-year warranty and free lifetime technical support. The StarTech.com Advantage - Link loss forwarding, remote status monitoring help ensure maximum up-time - Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility - Rugged steel casing for added durability in harsh environments
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
ET91000SM402
GTIN / Barcode
0065030846219
Brand Name
StarTech.com
Product Name
StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km - 1000 Mbps
Mfr. Part Number
ET91000SM402
GTIN / Barcode
0065030846219
Network
Maximum data transfer rate
2000 Mbit/s
Converter input interface
1000Base-T
Converter output interface
1000Base-LX, 1000Base-SX
Ethernet interface type
Gigabit Ethernet
Ethernet LAN data rates
1000 Mbit/s
Auto MDI/MDI-X
Yes
Duplex system
Full, Half
Performance
Maximum transfer distance
40000 m
Wavelength
1310 nm
Fiber mode structure
Single-mode
Mean time between failures (MTBF)
65000 h
Features
Internal
No
Plug and Play
Yes
Product colour
Black
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Fiber ports quantity
1
Fiber optic connector
SC
DC-in jack
Yes
Power
Output voltage
12 V
Output current
1 A
Power consumption (typical)
4 W
External power adapter
Yes
Weight & dimensions
Weight
600 g
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Packaging content
Manual
Yes
Packaging data
Package width
140 mm
Package depth
205 mm
Package height
91 mm
Package weight
700 g
Certificates
Compliance certificates
RoHS
Certification
CE, FCC
Logistics data
Harmonized System (HS) code
85176990
Other features
Dimensions (WxDxH)
95 x 160 x 20 mm
Full duplex
Yes
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Networking & Communications
