Turn two M.2 SATA drives into ultra-fast, portable storage with RAID for increased performance or redundancy
This dual M.2 SATA enclosure with RAID makes it easy to add ultra-fast, portable external storage to your USB-C™ or USB-A enabled laptop, tablet, smartphone or desktop computer. Its multiple RAID modes provide increased capacity, improved performance, or data redundancy.
Access your external data at greater speeds
Quickly access, transfer, and backup your files wherever you go. This dual-slot M.2 RAID enclosure enables you to easily access your data by creating a high-performance, ultra-portable storage solution using two M.2 (NGFF) SATA SSDs. It’s ideal for creative professionals, such as photographers and videographers, as well as professionals in corporate, educational and government sectors who need fast access to important data files, while out in the field or back at the office.
The RAID enclosure enables you to leverage the speed of your M.2 (NGFF) SATA drives by taking advantage of USB 3.1 Gen 2, with data transfer rates of up to 10Gbps. It ensures easy access to your files for data migration and data backups so that you can safeguard important data at all times.
Increase performance and data redundancy
With multiple RAID options, the M.2 RAID enclosure enables you to gain increased storage size, performance, or redundancy. You can enjoy the peace of mind of knowing your files are continually backed up, or take advantage of greater speed and capacity offered by a combined solution. The enclosure supports RAID 0, RAID 1, Spanning, and JBOD, enabling you to choose your preferred backup mode. It also supports SSD TRIM to prolong drive lifespan and performance.
Make your data more portable
The dual M.2 SATA enclosure provides a highly portable storage solution. With its compact design, you can tuck it away inside your laptop bag or carrying case and take it anywhere - to the office, the lab, or for mobile use, so that you can access your data wherever you go. Engineered with a solid aluminum housing, the dual-slot M.2 SATA enclosure helps to safeguard your data wherever you go.
The M.2 SATA RAID enclosure is powered directly from the USB port on your device, so no external power is required. It comes with two USB cables (USB-C to Micro-B and USB-A to Micro-B) for flexible use with the latest laptops and tablets equipped with a USB-Type C™ port as well as legacy devices. The enclosure is OS independent, with no additional software or driver installation required, and is compatiIt’s also compatible with a Thunderbolt™ 3 USB-C port.
The SM22BU31C3R includes all required drive installation tools and hardware and is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-SM22BU31C3R
GTIN / Barcode
0065030870757
Brand Name
StarTech.com
Product Name
StarTech.com Dual-Slot Drive Enclosure for M.2 SATA SSDs - USB 3.1 (10Gbps) - RAID - TAA
Mfr. Part Number
STA-SM22BU31C3R
GTIN / Barcode
0065030870757
Storage
Number of storage drives supported
2
Storage drive size
M.2
Supported storage drive interfaces
M.2, Serial ATA, Serial ATA II, Serial ATA III
Supported storage drive lengths
80 mm
RAID levels
0, 1, BIG, JBOD
Maximum storage capacity
2 TB
Ports & interfaces
USB connectivity
Yes
USB version
3.2 Gen 2 (3.1 Gen 2)
USB connector type
Micro-USB B
USB connector gender
Female
USB ports quantity
1
Integrated USB cable
No
Design
Product type
SSD enclosure
Product colour
Black
Material
Aluminium
LED indicators
Yes
Number of fans
0 fan(s)
Certification
CE, FCC
Performance
Data transfer rate
10 Gbit/s
Chipset
ASMedia - ASM1352R
UASP support
Yes
Mean time between failures (MTBF)
35000 h
Port multiplier
Yes
Power
Power source type
USB
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 90%
Weight & dimensions
Width
80 mm
Depth
100 mm
Height
15 mm
Weight
96 g
Package width
131 mm
Package depth
162 mm
Package height
32 mm
Package weight
195 g
Packaging content
Cables included
USB
Screws included
Yes
Screwdriver included
Yes
Manual
Yes
Technical details
Compliance certificates
RoHS
Logistics data
Harmonized System (HS) code
84733080
Master (outer) case width
487 mm
Master (outer) case length
543 mm
Master (outer) case height
337 mm
Products per master (outer) case
100 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Storage (SSD/HDD/NAS)
