Build a RAID array with two mSATA SSDs that can be installed into a single 2.5in SATA bay
Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-25SAT22MSAT
GTIN / Barcode
0065030855617
Brand Name
StarTech.com
Product Name
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA
Mfr. Part Number
STA-25SAT22MSAT
GTIN / Barcode
0065030855617
Ports & interfaces
Host interface
SATA
Output interface
mSATA
SATA revision
3.0
Port multiplier
Yes
Design
Internal
Yes
Product colour
Black, Green
Mean time between failures (MTBF)
5101299 h
Hot-swap
No
Certification
CE, FCC
Features
Chipset
JMicron JMS562
Data transfer rate (max)
6 Gbit/s
RAID levels
0, 1, BIG, JBOD
Plug and Play
Yes
Operational conditions
Operating temperature (T-T)
-40 - 85 °C
System requirements
Windows operating systems supported
Yes
Mac operating systems supported
Yes
Linux operating systems supported
Yes
Technical details
Compliance certificates
RoHS
Weight & dimensions
Width
70 mm
Depth
97 mm
Height
7 mm
Weight
39 g
Packaging data
Mounting brackets included
Yes
Quick installation guide
Yes
Package width
143 mm
Package depth
175 mm
Package height
34 mm
Package weight
107 g
Logistics data
Harmonized System (HS) code
84733020
Products per master (outer) case
60 pc(s)
Master (outer) case width
382 mm
Master (outer) case length
498 mm
Master (outer) case height
322 mm
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Storage (SSD/HDD/NAS)
