Control up to 8 VGA and USB computers from a single keyboard, mouse and monitor
The SV831DUSBU 8 Port 1U Rack Mount USB KVM Switch with OSD offers a dependable computer management tool that allows you to control up to 8 USB-connected computers from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hotkey commands or front panel push-buttons, and offers added configuration options and convenience through an On Screen Display (OSD).
A suitable addition to server room operations, the 8 port switch can be rack mounted into 1U of cabinet space, and can be cascaded with multiple KVM switches to deliver control of up to 64 computers from this single switch.
The SV831DUSBU only works with specific 2-in-1 VGA and USB cables (sold separately), a list of StarTech.com approved cables are below:
6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
10 ft Ultra Thin USB VGA 2-in-1 KVM Cable
15 ft Ultra Thin USB VGA 2-in-1 KVM Cable
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
SV831DUSBU
GTIN / Barcode
0065030837255
Brand Name
StarTech.com
Product Name
StarTech.com 8 Port 1U Rackmount USB KVM Switch with OSD - TAA
Mfr. Part Number
SV831DUSBU
GTIN / Barcode
0065030837255
Ports & interfaces
Number of computers controlled
8
Keyboard port type
USB
Mouse port type
USB
Video port type
VGA
VGA (D-Sub) ports quantity
9
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
2
Audio connections
No
DC-in jack
Yes
Performance
Maximum resolution
1920 x 1440 pixels
Plug and Play
Yes
Daisy chain
Yes
Design
Rack mounting
Yes
Rack capacity
1U
Product colour
Black
Housing material
Steel
LED indicators
Yes
Mean time between failures (MTBF)
150000 h
Certification
CE, FCC, TAA, REACH
Display
Built-in display
No
On Screen Display (OSD)
Yes
Power
Input voltage
100 - 240 V
Input current
0.8 A
Output voltage
12 V
Output current
1.5 A
Power plug type
Type M
Compatible power plug types
EU, UK, US
Sustainability
Compliance certificates
RoHS
Operational conditions
Operating temperature (T-T)
5 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
540 mm
Depth
180 mm
Height
45 mm
Weight
2.9 kg
Packaging data
Package width
89 mm
Package depth
573 mm
Package height
268 mm
Package weight
3.3 kg
Packaging content
Manual
Yes
AC adapter included
Yes
Rubber feet
Yes
Other features
Connectivity technology
Wired
Dimensions (WxDxH)
540 x 180 x 45 mm
Ports quantity
8
Power requirements
110 - 240 AC
Audio support
No
IP control
No
Logistics data
Harmonized System (HS) code
85176200
Master (outer) case width
607 mm
Master (outer) case length
286 mm
Master (outer) case height
337 mm
Products per master (outer) case
4 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Switches
