Control up to 8 USB computers with DVI or HDMI® video, from one keyboard, mouse and monitor
The SV831DVIU 8-Port 1U Rack Mount DVI USB KVM Switch lets you control up to 8 USB-connected computers (each with DVI or HDMI display output) from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hot-key commands or front panel push-buttons. Supporting digital resolutions up to 1920x1200 via DVI or HDMI connection (using DVI to HDMI adapter - see accessories), the KVM provides the high resolutions recommended for newer displays, allowing you to take full advantage of your monitor/screen capability.
A perfect addition to any server room or software test lab, this 8-port switch can be rack-mounted into 1U of cabinet space.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
Note: This KVM supports digital signals only, and cannot be used with DVI-to-VGA adapters.
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
SV831DVIU
GTIN / Barcode
0065030842303
Brand Name
StarTech.com
Product Name
StarTech.com 8 Port 1U Rackmount DVI USB KVM Switch - TAA
Mfr. Part Number
SV831DVIU
GTIN / Barcode
0065030842303
Ports & interfaces
Number of computers controlled
8
Keyboard port type
USB
Mouse port type
USB
Video port type
DVI-I
USB 2.0 ports quantity
10
Audio connections
No
Network
Ethernet LAN
No
Performance
Maximum resolution
1920 x 1200 pixels
Maximum analog resolution
1920 x 1200 pixels
Daisy chain
No
Design
Rack mounting
Yes
Rack capacity
1U
Product colour
Black
Housing material
Steel
LED indicators
Yes
Hot keys
Yes
Mean time between failures (MTBF)
45254 h
Certification
CE, FCC
Power
Input voltage
100-240 V
Input current
1.8 A
Output voltage
12 V
Output current
4 A
External power adapter
Yes
Power plug type
Type M
Compatible power plug types
AU, EU, UK, US
Sustainability
Compliance certificates
RoHS
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
438 mm
Depth
180 mm
Height
44 mm
Weight
3.5 kg
Packaging data
Package width
595 mm
Package depth
265 mm
Package height
90 mm
Package weight
3.77 kg
Packaging content
Manual
Yes
Rack mount kit
Yes
Other features
IP control
Yes
Logistics data
Harmonized System (HS) code
85176200
Master (outer) case width
288 mm
Master (outer) case length
610 mm
Master (outer) case height
408 mm
Products per master (outer) case
4 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Switches
