StarTech.com
StarTech.com 7-Port USB 2.0 Hub - Metal Industrial USB-A with ESD & 350W Surge Protection -
Availability: In StockMfr. Part#: STA-HB20A7AME
$255.05Save 5% · $12.15
$242.90USD
Prices shown in USD. Taxes, duties and freight are quoted separately.
Call 856-283-0457 for volume pricing.
Business & Quantity Discounts Available
Flexible Terms for Qualified Organizations
Supporting Commercial, Government & Education Buyers
Extended Temperature| 15kV Air | 8kV Contact | Metal | Mountable | DIN Rail | 480 Mbps
This TAA compliant 7-port industrial USB 2.0 hub gives you the scalability you need in harsh industrial environments, product and repair labs, conference rooms or office workstations. With its rugged industrial grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments.
Perfect for Harsh Environments
This industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-48V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities.
Perfect for more extreme environments, the rugged hub also supports a wide operating temperature range (-40°C to 85°C) and offers ESD protection to each USB port, which can help prevent damage to your connected devices.
Connect More USB Devices
Designed for a high volume of connections, this robust USB 2.0 hub offers seven connection ports, for connecting more USB devices and peripherals.
Locate the Hub Where You Need It Most
With versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets, included DIN mount rails, and an included 2-meter USB host cable, you can securely mount the USB 2.0 hub to most surfaces such as a wall, under a desk or rack.
StarTech.com offers an external power adapter, ITB20D3250, sold separately. The universal DC power adapter can be used as an alternative, back up or replacement power supply for StarTech.com’s line of industrial USB hubs.
Works with Older USB Devices
The rugged USB hub supports the full 480 Mbps bandwidth of USB 2.0 and is backward compatible with previous USB devices.
The HB20A7AME is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-HB20A7AME
GTIN / Barcode
0065030878616
Brand Name
StarTech.com
Product Name
StarTech.com 7-Port USB 2.0 Hub - Metal Industrial USB-A Hub with ESD & 350W Surge Protection - Extended Operating Temp -40 to 185°F - Din Rail/Wall/Desk Mountable - USB Expander Hub
Mfr. Part Number
STA-HB20A7AME
GTIN / Barcode
0065030878616
Ports & interfaces
Host interface
USB 2.0 Type-B
Hub interfaces
USB 2.0
USB 2.0 ports quantity
7
Ports quantity
7
Terminal block port
Yes
Features
Data transfer rate
480 Mbit/s
Product colour
Black
Housing material
Metal
Surge protection
Yes
LED indicators
Power
Plug and Play
Yes
Certification
CE, FCC, TAA, RoHS, REACH
Power
Power consumption (typical)
28 W
Input voltage
7 - 48 V
Input current
4 A
Weight & dimensions
Width
63 mm
Depth
130 mm
Height
42 mm
Weight
404 g
Packaging data
Package width
166 mm
Package depth
242 mm
Package height
55 mm
Package weight
600 g
Packaging content
Cables included
USB
Manual
Yes
DIN rail kit included
Yes
Operational conditions
Operating temperature (T-T)
-40 - 85 °C
Storage temperature (T-T)
-40 - 85 °C
Operating relative humidity (H-H)
5 - 95%
Logistics data
Master (outer) case width
435 mm
Master (outer) case length
565 mm
Master (outer) case height
260 mm
Products per master (outer) case
20 pc(s)
Harmonized System (HS) code
84719000
Other features
Chipset
Genesys Logic - GL852GT
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Licenses & Renewals
