Use this 4K receiver with your HDMI extender over IP kit (ST12MHDLAN4K) to build scalable/cost-effective AVoIP solutions
This HDMI® over IP Receiver works with the HDMI over IP Extender Kit [%product id="ST12MHDLAN4K (sold separately). Designed for IT professionals, system integrators, and digital signage specialists, this solution delivers unmatched flexibility for scaling video distribution without the limitations of traditional HDMI splitters or fixed extenders.
Scalable HDMI Over IP
Easily expand your A/V distribution setup and build dynamic video walls using the ST12MHDLAN4K extender kit and additional receivers:
• One-to-Many : Connect up to 16 receivers to a single transmitter, ideal for broadcasting HDMI over IP to multiple displays • Many-to-Many : Integrate up to 16 [%product id="ST12MHDLAN4K extender kits and additional ST12MHDLAN4R receivers with a maximum of 16 transmitters and 256 receivers.
Centralized Video Control App
The included iOS/Android Video Control App empowers administrators to name sources and displays, switch inputs, and configure video walls, all from a mobile device. With RS232 passthrough, TVs or serial-controlled devices can be managed remotely through the same network.
Flexible Installations for Any Environment
Perfect for digital signage in retail, hospitality, and corporate settings, as well as command centers or other mission-critical environments. The kit includes mounting hardware for clean shelf or rack installations and supports both static and dynamic signage needs.
Note: For optimal performance, a managed network switch with IGMP is recommended when using more than one transmitter or more than four receivers. Non-managed switches may impact the performance of other devices on your network. Jumbo frames support must be enabled to stream 4K video effectively.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-ST12MHDLAN4R
GTIN / Barcode
0065030868969
Brand Name
StarTech.com
Product Name
StarTech.com 4K HDMI over IP Receiver for ST12MHDLAN4K, IP Extender with Video Control App, Support for AVoIP Video Wall - TAA
Mfr. Part Number
STA-ST12MHDLAN4R
GTIN / Barcode
0065030868969
Features
Type
AV receiver
Maximum resolution
3840 x 2160 pixels
Cable types supported
Cat5e
Maximum transfer distance
100 m
Maximum refresh rate
30 Hz
Audio system
stereo
Supported video modes
720p, 1080p, 2160p
Supported graphics resolutions
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160
Material
Aluminium
Daisy chain
Yes
Product colour
Black
Ports & interfaces
Connectivity technology
Wired
RJ-45 output ports
1
Number of HDMI outputs
1
Audio input
3.5mm
Audio output
3.5mm
RJ-11 ports quantity
2
Remote (IR) input
1
Remote (IR) output
1
DC-in jack
Yes
Power
AC input voltage
100 - 240 V
Operating voltage
12 V
Input current
0.6 A
Output current
1.5 A
Power consumption (typical)
18 W
Power plug type
Type M
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
117 mm
Depth
131 mm
Height
30 mm
Weight
594 g
Packaging data
Package width
211 mm
Package depth
297 mm
Package height
67 mm
Package weight
1.2 kg
Packaging content
AC adapter included
Yes
Cables included
LAN (RJ-45), Phone (RJ-11)
Quick start guide
Yes
Mounting brackets included
Yes
Technical details
Sustainability compliance
Yes
Compliance certificates
CE, RoHS
Logistics data
Master (outer) case width
326 mm
Master (outer) case length
402 mm
Master (outer) case height
262 mm
Products per master (outer) case
6 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
VoIP & Telephony
