Home/Networking & Communications/Network Cabling/StarTech.com 4-Port USB 2.0 Extender Hub over Single CAT5e/CAT6 Ethernet Cable (RJ45) - 330ft (100m) - USB Extender Hub Adapter Kit - Metal Housing - Externally Powered - 480 Mbps - TAA
StarTech.com
StarTech.com 4-Port USB 2.0 Extender Hub over Single CAT5e/CAT6 Ethernet Cable (RJ45) - 330ft
Availability: In StockMfr. Part#: STA-USB2004EXT100
$451.06Save 5% · $21.48
$429.58USD
Prices shown in USD. Taxes, duties and freight are quoted separately.
Call 856-283-0457 for volume pricing.
Business & Quantity Discounts Available
Flexible Terms for Qualified Organizations
Supporting Commercial, Government & Education Buyers
USB Extender Over CAT5e/CAT6/CAT7 | Rugged Enclosure | 2-Year Warranty
This USB 2.0 extender enables you to connect up to four USB 2.0 devices over distances of up to 330 feet (100 meters), over standard Cat5e/Cat6/Cat7 Ethernet LAN cabling.
Hi-Speed USB Performance
With data bandwidth of up to 480Mbps and no software installation required, the USB extender over Cat5e, Cat6, or Cat7 network cabling offers a fast, easy, and versatile solution for business or commercial applications with durable metal housing, an included surface-mounting bracket kit and simple plug-and-play installation.
Plus, the 330 ft. (100 m) USB extender provides up to the full 500 mA of power (with the use of an external power adapter at the remote end) allowing for greater compatibility with bus-powered USB devices.
Compatible with USB 2.0/1.1/1.0 Devices
Connecting low-speed peripherals or HID devices isn't a problem. This versatile USB over network extender is backward compatible with legacy USB 1.0/1.1 devices, so you can access up to four different types of USB devices from your remote location, far away from the host computer.
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales
USB2004EXT100 is backed by a StarTech.com 2-year warranty and free lifetime 24/5 North American based, multi-lingual support.
Product Specifications
Manufacturer
STARTECH.COM
Manufacturer Part Number
STA-USB2004EXT100
GTIN / Barcode
0065030892971
Brand Name
StarTech.com
Product Name
StarTech.com 4-Port USB 2.0 Extender Hub over Single CAT5e/CAT6 Ethernet Cable (RJ45) - 330ft (100m) - USB Extender Hub Adapter Kit - Metal Housing - Externally Powered - 480 Mbps - TAA
Mfr. Part Number
STA-USB2004EXT100
GTIN / Barcode
0065030892971
Technical details
Type
Console transmitter & receiver
Data transfer rate
480 Mbit/s
Maximum transfer distance
100 m
Product colour
Black
Housing material
Aluminium
LED indicators
Status
Rubber feet
Yes
Cable types supported
Cat5e, Cat6
Compliance certificates
CE, RoHS
Ports & interfaces
USB 2.0 Type-A ports quantity
4
Mini-USB 2.0 ports quantity
2
RJ-45 ports quantity
2
Weight & dimensions
Width
60 mm
Depth
100 mm
Height
22 mm
Weight
143 g
Package width
235 mm
Package depth
153 mm
Package height
65 mm
Package weight
716 g
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Packaging content
Cables included
LAN (RJ-45), USB
Quick start guide
Yes
AC adapter included
Yes
Power
Power consumption (typical)
10 W
Input voltage
100 - 240 V
Output voltage
5 V
Output current
2 A
Logistics data
Harmonized System (HS) code
84733020
Master (outer) case width
410 mm
Master (outer) case length
323 mm
Master (outer) case height
275 mm
Products per master (outer) case
12 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Cabling
Customer reviews
No reviews yet. If you have bought this,
yours would be the first.
