Control up to 16 USB computers from a single keyboard, mouse and monitor
The SV1631DUSBU 16 Port 1U Rack Mountable USB KVM Switch with OSD lets you control 16 USB computers from a single console (USB keyboard, USB mouse, VGA monitor).
Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.
Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet with the included brackets, and can be cascaded with multiple KVM switches to deliver control of up to 136 computers from this single switch. Rear cable connections help to eliminate cable tangles and minimize workspace disruption.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
The SV1631DUSBU only works with specific 2-in-1 VGA and USB cables (sold separately), a list of StarTech.com approved cables are below:
6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
6 ft Ultra Thin USB VGA 2-in-1 KVM Cable
10 ft Ultra Thin USB VGA 2-in-1 KVM Cable
15 ft Ultra Thin USB VGA 2-in-1 KVM Cable
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
SV1631DUSBU
GTIN / Barcode
0065030837224
Brand Name
StarTech.com
Product Name
StarTech.com 16 Port 1U Rackmount USB KVM Switch with OSD - TAA
Mfr. Part Number
SV1631DUSBU
GTIN / Barcode
0065030837224
Ports & interfaces
Number of computers controlled
16
Keyboard port type
USB
Mouse port type
USB
Video port type
VGA
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
2
Audio connections
No
DC-in jack
Yes
Performance
Maximum resolution
1920 x 1440 pixels
Plug and Play
Yes
Daisy chain
Yes
Design
Rack mounting
Yes
Rack capacity
1U
Product colour
Black
Housing material
Steel
LED indicators
Yes
Display
Built-in display
No
Power
Input voltage
110-240 V
Input current
0.8 A
Output voltage
12 V
Output current
1.5 A
Power plug type
Type M
Operational conditions
Operating temperature (T-T)
5 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
5 - 80%
Weight & dimensions
Width
540 mm
Depth
180 mm
Height
45 mm
Weight
3.1 kg
Packaging data
Package width
597 mm
Package depth
265 mm
Package height
91 mm
Package weight
3.53 kg
Packaging content
Manual
Yes
AC adapter included
Yes
Other features
Audio support
No
IP control
No
Logistics data
Harmonized System (HS) code
85176200
Master (outer) case width
613 mm
Master (outer) case length
290 mm
Master (outer) case height
412 mm
Products per master (outer) case
4 pc(s)
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Network Switches
