Convert and extend a 10/100 Mbps Ethernet connection up to 18.6 miles/30km over Single Mode SC fiber The ET90110SM302 10/100 Mbps Single Mode Fiber Media Converter SC (30 km) lets you extend a Fast Ethernet network (10/100) over single mode fiber, at distances up to 30 km (18.6 miles). A cost-effective solution for connecting a 10/100 Mbps Ethernet (10/100Base-T) network to remote network segments over a 100Base-FX fiber backbone, the media converter is designed to offer a durable and convenient Ethernet to fiber solution, with an all-steel chassis, and simple plug-and-play installation with minimal configuration required. For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). Backed by a StarTech.com 2-year warranty and free lifetime technical support. The StarTech.com Advantage - Link loss forwarding, remote monitoring of status ensures maximum up-time - Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility - Rugged steel casing for durability in harsh environments
Product Specifications
Manufacturer
Startech.com
Manufacturer Part Number
ET90110SM302
GTIN / Barcode
0065030846264
Brand Name
StarTech.com
Product Name
StarTech.com 10/100 Mbps Single Mode Fiber Media Converter SC 30 km
Mfr. Part Number
ET90110SM302
GTIN / Barcode
0065030846264
Network
Maximum data transfer rate
200 Mbit/s
Converter input interface
10Base-T
Converter output interface
100Base-FX
Ethernet interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Auto MDI/MDI-X
Yes
Duplex system
Full, Half
Performance
Maximum transfer distance
30000 m
Wavelength
1310 nm
Fiber mode structure
Single-mode
Features
Internal
No
Plug and Play
Yes
Product colour
Black
Ports & interfaces
Connectivity technology
Wired
Ethernet LAN (RJ-45) ports
1
Fiber ports quantity
1
Fiber optic connector
SC
DC-in jack
Yes
Power
Output voltage
12 V
Output current
1 A
External power adapter
Yes
Weight & dimensions
Weight
600 g
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Packaging content
Manual
Yes
Packaging data
Package width
206 mm
Package depth
137 mm
Package height
89 mm
Package weight
766 g
Certificates
Compliance certificates
RoHS
Certification
CE, FCC
Logistics data
Harmonized System (HS) code
85176990
Other features
Dimensions (WxDxH)
95 x 160 x 20 mm
Full duplex
Yes
Brand
StarTech.com
Availability
In Stock
Price Currency
USD
Category
Networking & Communications
