Product Details

Built for unparalleled performance on the Intel Z890 chipset and Core Ultra processors, the MEG Z890 GODLIKE equips true Wi-Fi 7, 10G Super LAN, Thunderbolt 5, Supplemental PCIe Power, and the revolutionary Dynamic Dashboard III. Dominate tournaments and immerse in extreme gaming with the MEG Z890 GODLIKE.

Dynamic Dashboard III

A 3.99-inch full-color LCD offers real-time hardware monitoring, troubleshooting, BIOS update status, clock display, and personalization options, significantly enhancing the overall user experience.

EZ LINK

The GODLIKE-exclusive EZ Link design consolidates most of the case front panel headers, fan headers, and RGB headers into the EZ Bridge and EZ Control Hub, simplifying installation and creating a cleaner aesthetic.

M.2 XPANDER-Z SLIDER GEN5

In addition to the 6 built-in M.2 slots, the MEG Z890 GODLIKE also comes with the all-new M.2 XPANDER-Z SLIDER GEN5 card, providing even more high-speed storage expansion options.

Product Specifications

Manufacturer	MSI
Manufacturer Part Number	Z890GODLIKE
GTIN / Barcode	4711377260770
Brand Name	MSI
Product Name	MSI MEG Z890 GODLIKE motherboard Intel Z890 LGA 1851 (Socket V1) ATX

Processor
Mfr. Part Number	Z890GODLIKE
GTIN / Barcode	4711377260770
Processor manufacturer	Intel
Processor socket	LGA 1851 (Socket V1)
Compatible processor series	Intel Core Ultra (Series 2)
Supported processor sockets	LGA 1851
Maximum internal memory supported by processor	256 GB
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dual-channel
ECC сompatibility	Non-ECC
Supported memory clock speeds	5600,6400,7200,9200 MHz
Supported memory clock speed (max)	9200 MHz
Maximum internal memory	256 GB
Storage controllers
Supported storage drive types	SSD
Supported storage drive interfaces	M.2, SATA III
Number of storage drives supported	8
RAID support	Yes
RAID levels	0, 1, 5, 10
Graphics
On-board graphics card	No
Internal I/O
USB 2.0 connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	4
USB 3.2 Gen 2x2 connectors	1
Number of SATA III connectors	4
Total number of SATA connectors	4
S/PDIF out connector	Yes
Front panel connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
Chassis intrusion connector	Yes
EPS power connector (8-pin)	Yes
Number of EPS power connectors (8-pin)	1
TPM connector	Yes
RGB LED pin header	Yes
Number of RGB LED pin headers	1
Rear panel I/O ports
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
DisplayPorts quantity	2
DisplayPort version	2.1
S/PDIF out port	Yes
Thunderbolt ports quantity	4
Network
Ethernet LAN	Yes
Ethernet interface type	10 Gigabit Ethernet
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth	Yes
Bluetooth version	5.4
Features
Motherboard chipset	Intel Z890
Audio chip	Realtek ALC4082
Audio output channels	7.1 channels
Product colour	Black
Component for	PC
Motherboard form factor	ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 11 x64
Expansion slots
PCI Express x4 slots	1
PCI Express x16 slots	2
Number of M.2 (M) slots	8
1st M.2 largest key size	2280
1st M.2 highest PCI Express generation	5.0
2nd M.2 largest key size	2280
2nd M.2 highest PCI Express generation	5.0
3rd M.2 largest key size	2280
3rd M.2 highest PCI Express generation	4.0
4th M.2 largest key size	2280
5th M.2 largest key size	2280
6th M.2 largest key size	2280
BIOS
Clear CMOS button	Yes
Weight & dimensions
Width	277 mm
Depth	304.8 mm
