Product Details

Built for Sustainability
The Cubi NUC Series blends business-centric design with environmental responsibility - an embodiment of MSI's dedication to sustainability. Our commitment extends to incorporating sustainable materials in both our product design and packaging, protecting the earth through our actions. By utilizing sustainable materials such as PCR plastics, recycled pulp from FSC™-certified forests, more active management of substances used in manufacturing processes, and the continued use of renewable energy in production processes, we ensure the products' durability and a commitment to a greener world.

The Cubi NUC Series embodies sustainable value and heightened productivity.

Product Specifications

Manufacturer	MSI
Manufacturer Part Number	CUBINUC1M011
GTIN / Barcode	0824142369852
Brand Name	MSI
Product Name	MSI Cubi NUC 1M-011US Intel Core 3 100U 8 GB DDR5-SDRAM 500 GB SSD Windows 11 Home Mini PC Black

Processor
Mfr. Part Number	CUBINUC1M011
GTIN / Barcode	0824142369852
Processor manufacturer	Intel
Processor family	Intel Core 3
Processor generation	Intel Core (Series 1)
Processor model	100U
Processor cores	6
Processor threads	8
Processor boost frequency	4.7 GHz
Performance cores	2
Efficient cores	4
Performance-core Max Turbo Frequency	4.7 GHz
Efficient-core Max Turbo Frequency	3.3 GHz
Performance-core base frequency	1.2 GHz
Efficient-core base frequency	0.9 GHz
Processor cache	10 MB
Processor cache type	Smart Cache
Processor base power	15 W
Maximum turbo power	55 W
Memory
Internal memory	8 GB
Maximum internal memory	64 GB
Internal memory type	DDR5-SDRAM
Memory layout (slots x size)	1 x 8 GB
Memory slots	2x SO-DIMM
Memory clock speed	5600 MHz
Storage
Total storage capacity	500 GB
Storage media	SSD
Optical drive type	No
Total SSDs capacity	500 GB
Number of SSDs installed	1
SSD capacity	500 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Graphics
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card family	Intel® Graphics
On-board graphics card model	Intel® Graphics
Performance
Market positioning	Business
Motherboard chipset	Intel SoC
Motherboard form factor	NUC
Trusted Platform Module (TPM)	Yes
Product type	Mini PC
Trusted Platform Module (TPM) version	2.0
Built-in speaker(s)	No
Network
Ethernet LAN	Yes
LAN controller	Intel I226-V
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Bluetooth	Yes
Bluetooth version	5.3
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Intel® Thunderbolt 4	Yes
Thunderbolt 4 ports quantity	2
HDMI ports quantity	2
HDMI version	1.4b/2.1
Ethernet LAN (RJ-45) ports	2
Combo headphone/mic port	Yes
Microphone in	No
DVI port	No
DC-in jack	Yes
Power
Power supply	120 W
Design
VESA mounting	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Product colour	Black
Housing material	Plastic
Software
Operating system installed	Windows 11 Home
Display
Display included	No
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 85%
Storage relative humidity (H-H)	0 - 90%
Weight & dimensions
Width	132.5 mm
Depth	135.6 mm
Height	50.1 mm
