D-Link
D-Link DXS-1210-10MP 10-Port 10G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports
Mfr. Part# DXS-1210-10MP
US$1,567.60
US$1,492.95
Prices shown in USD. Taxes, duties and freight are quoted separately. Call 856-283-0457 for volume pricing.
| Manufacturer | D-Link Systems |
|---|---|
| Manufacturer Part Number | DXS-3610-54S/SI |
| GTIN / Barcode | 0790069452116 |
| Brand Name | D-Link |
| Product Name | D-Link 48-port 10G SFP+ Layer 3 Stackable 10G Managed Switch |
| Mfr. Part Number | DXS-3610-54S/SI |
|---|---|
| GTIN / Barcode | 0790069452116 |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | No |
| SFP+ module slots quantity | 48 |
| Console port | RJ-45 |
| QSFP28 ports quantity | 6 |
| USB 2.0 ports quantity | 1 |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Virtual LAN features | MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN |
| Data transmission | |
| Switching capacity | 2211.84 Gbit/s |
| Forwarding rate | 1607.04 Mpps |
| MAC address table | 294912 entries |
| Number of queues | 8 |
| Static route | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9436 |
| Packet buffer memory | 32 MB |
| Security | |
| DHCP features | DHCP client, DHCP server, DHCP snooping |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| BPDU filtering/protection | Yes |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | SNMP v1/v2c/v3 |
| Design | |
| Rack mounting | Yes |
| Stackable | Yes |
| Form factor | 1U |
| Product colour | Black |
| Number of fans | 5 fan(s) |
| Electromagnetic compatibility | FCC, CE, C-Tick, IC, VCCI |
| Performance | |
| Physical stacking (units) | 12 |
| Virtual stacking (units) | 32 |
| Noise level | 79.4 dB |
| Mean time between failures (MTBF) | 94262 h |
| Power | |
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 120.6 W |
| Power consumption (max) | 320.8 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 1083 BTU/h |
| Weight & dimensions | |
| Width | 441 mm |
| Depth | 487.4 mm |
| Height | 43.5 mm |
| Weight | 9.8 kg |
| Certificates | |
| Certification | CB, cUL, LVD |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Brand | D-Link |
| Availability | In Stock |
| Price Currency | USD |
| Category | Transceivers & Modules |
