Name: ASUS ROG -THOR-1200P3-WHITE-GAMING power supply unit 1200 W 20+4 pin ATX
Brand: ASUS
SKU: ROG-THOR1200P3WHITEGAMING
Price: 833.74 USD
Availability: InStock

856-283-0457 sales@centraldistributor.com 81 Erial Rd Apt B, Clementon, NJ, 08021

Home /Computers & IT Hardware /Power & UPS /ASUS ROG -THOR-1200P3-WHITE-GAMING power supply unit 1200 W 20+4 pin ATX ATX

Product Details

ROG THOR 1200W PLATINUM III WHITE EDITION
ULTIMATE POWER.
UNMATCHED STABILITY.

The ROG Thor 1200W Platinum III White Edition delivers the ultimate power and stability demanded by gamers. A next-gen GaN MOSFET delivers superior efficiency, and “GPU-First” voltage sensing features a patented-intelligent voltage stabilizer, ensuring top-tier performance and stability. Meanwhile, there is Turbo Mode for maximum cooling when overclocking or for other demanding workloads.

The ROG Thor 1200W Platinum III White Edition also features the signature Thor OLED display, now upgraded for easy magnetic attachment – it can be swapped to either side of the unit to accommodate fan-up or fan-down PSU installation.

Product Specifications

Manufacturer	ASUS
Manufacturer Part Number	ROG-THOR1200P3WHITEGAMING
GTIN / Barcode	4711636125499
Brand Name	ASUS
Product Name	ASUS ROG -THOR-1200P3-WHITE-GAMING power supply unit 1200 W 20+4 pin ATX ATX

Power
Mfr. Part Number	ROG-THOR1200P3WHITEGAMING
GTIN / Barcode	4711636125499
Total power	1200 W
AC input voltage	100 - 240 V
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	125 W
Combined power (+12V)	1200 W
Combined power (+5V)	125 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	30 A
Max output current (+12V)	100 A
Max output current (+5V)	25 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Power protection features	Overheating, Over current, Over power, Over voltage, Short circuit, Under power
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	61 cm
Number of SATA power connectors	7
SATA power cable length	400,120 mm
Peripheral (Molex) power connectors (4-pin)	6
Peripheral (Molex) power cable length	400,150 mm
PCI Express power connectors (6+2 pin)	4
PCI Express power connectors (16-pin)	1
PCI Express power cable length	75 cm
CPU power connector (4+4 pin)	Yes
CPU power cable length	100 cm
Cabling type	Fully-Modular
Performance
80 PLUS certification	80 PLUS Platinum
Purpose	PC
Power supply unit (PSU) form factor	ATX
ATX version	3.1
Mean time between failures (MTBF)	120000 h
Design
Product colour	White
Cooling type	Active
Number of fans	1 fan(s)
Fan location	Top
Illumination	Yes
On/off switch	Yes
Packaging content
Cables included	CPU, DC, PCIe, Peripheral (Molex), SATA
Weight & dimensions
Width	190 mm
Depth	150 mm
Height	86 mm
Weight	2.37 kg
Brand	ASUS
Availability	In Stock
Price Currency	USD
Category	Power & UPS
