Name: ASUS PRO Q870M-C-CSM Intel® Q870 LGA 1851 (Socket V1) micro ATX
Brand: ASUS
SKU: PROQ870M-C-CSM
Price: 262.49 USD
Availability: InStock

856-283-0457 sales@centraldistributor.com 81 Erial Rd Apt B, Clementon, NJ, 08021

Home /Computers & IT Hardware /Memory & Components /ASUS PRO Q870M-C-CSM Intel® Q870 LGA 1851 (Socket V1) micro ATX

Product Details

Micro-ATX Q870 business motherboard with Intel® vPro support and enhanced security, reliability and manageability
ASUS Pro business motherboards provide enhanced features to smooth your IT operations, including comprehensive system protection, 24/7 stability and reliability and an improved management suite for easier customization. Known as the world's biggest and best-known motherboard brand, ASUS provides world-class after-sales service and guaranteed long-term availability to maximize your investment over the product life cycle and offers a high-quality, TCO-optimized solution for your business computing-needs.

Product Specifications

Manufacturer	ASUS
Manufacturer Part Number	PROQ870M-C-CSM
GTIN / Barcode	4711387880586
Brand Name	ASUS
Product Name	ASUS PRO Q870M-C-CSM Intel® Q870 LGA 1851 (Socket V1) micro ATX

Processor
Mfr. Part Number	PROQ870M-C-CSM
GTIN / Barcode	4711387880586
Processor manufacturer	Intel
Processor socket	LGA 1851 (Socket V1)
Compatible processor series	Intel Core Ultra (Series 2)
Memory
Supported memory types	DDR5-SDRAM
Number of memory slots	4
Memory slots type	DIMM
Memory channels	Dual-channel
ECC сompatibility	Non-ECC
Supported memory clock speed (max)	6400 MHz
Maximum internal memory	256 GB
Unbuffered memory	Yes
Storage controllers
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Number of HDDs supported	4
Number of storage drives supported	6
RAID support	Yes
RAID levels	0, 1, 5, 10
Graphics
Parallel processing technology support	Not supported
On-board graphics card	No
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
Number of SATA III connectors	4
Front panel audio connector	Yes
Front panel connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
Number of CPU fan connectors	1
Number of chassis fan connectors	2
EPS power connector (8-pin)	Yes
Number of COM connectors	2
12V power connector	Yes
Rear panel I/O ports
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Ethernet LAN (RJ-45) ports	1
PS/2 ports quantity	2
HDMI ports quantity	1
DisplayPorts quantity	2
Microphone in	Yes
USB connector type	USB Type-A, USB Type-C
Network
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
LAN controller	Intel® I219-LM
Wi-Fi	No
Top Wi-Fi standard	Not available
Features
Motherboard chipset	Intel® Q870
Audio output channels	7.1 channels
Product colour	Multicolour
Component for	PC
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 x64, Windows 11
Expansion slots
PCI Express x1 (Gen 4.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
Number of M.2 (M) slots	2
BIOS
BIOS memory size	256 Mbit
Packaging data
Package width	270 mm
Package depth	263 mm
Package height	51.5 mm
Package weight	889.03 g
Weight & dimensions
Width	244 mm
Depth	244 mm
Height	50 mm
Other features
Weight	550.6 g
Brand	ASUS
Availability	In Stock
Price Currency	USD
Category	Memory & Components
