Product Details

19 inch Rack-Mountable
Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails, the unit will automatically switch to the alternate power source.

Quick Transfer Rate
Transfer rate is within the industry standard and within the time power supplies will typically drop loads. The transfer of one power source to another is seamless to the connected equipment avoiding disruption of equipment performance.

Wrap Around System Bypass
(3) Breaker maintenance bypass panel to isolate the UPS from the critical load
Meets UL Requirements

Product Specifications

Manufacturer	APC by Schneider Electric
Manufacturer Part Number	SBP3000RM2U
GTIN / Barcode	0731304212577
Brand Name	APC by Schneider Electric
Product Name	APC Service Bypass Panel- 100-120V; 30A; BBM; L5-30P input; (2) 5-20R (6) 5-15R output

Design
Mfr. Part Number	SBP3000RM2U
GTIN / Barcode	0731304212577
Product colour	Black
Ports & interfaces
Input connection type	NEMA L5-30P
Output connections	6x NEMA 5-15R 2x NEMA 5-20R
Features
Cable length	3.05 m
Power
AC input frequency	50 - 60 Hz
Load capacity	3000 VA
Maximum input current per phase	24 A
Maximum total current draw per phase	30 A
Certificates
Certification	CSA,EN 60950,GOST,IEC 60950,IEC 60950,UL 1778
Operational conditions
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-25 - 65 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Weight & dimensions
Width	432 mm
Depth	648 mm
Height	89 mm
Weight	13.6 kg
Packaging data
Package weight	24.6 kg
Package width	610 mm
Package depth	991 mm
Package height	203 mm
Brand	APC by Schneider Electric
